Scotsman AF 80 Self Contained Ice Flaker (73kg/24hr)
Scotsman AF 80 ice flaker for drinks, food display, laboratory and medical, food production and fish transport. The Scotsman range has a model to fit every application.
Specification
- Electronically controlled operation, with self-diagnostic functions with external alarm lights providing operational information for early alert and fast diagnosis of operating issues
- External Components constructed from corrosion-resistant stainless steel crafted for optimal aesthetic appeal through superior fit and finish
- Ergonomically convenient, slanted & disappearing storage bin door
- Front Access for Easier Maintenance
- Front-in, front-out airflow allows for built-in installations
- CFC Free R-134a Refrigerant
- Production 24hrs/kg: 73
- Storage kg: 25
- Weight: 50kg
- Packed: 58kg
- Dimensions: 535(w) x 626(d) x 889(h)mm
- Electrical Load: 230/50/1 - 13amp
- Water Consumption/24h: 64 ltr
- Max ambient temperature: 43°C
- PLEASE NOTE THIS MACHINE IS GRAVITY DRAIN
Technical
- Capacity 25 KG
- Power 330 Watt
- Refrigerant R134a
- Voltage 230V
- Warranty Manufacturers 2 years parts & labour
- Weight 50 KG
- Power Supply 13 Amp Plug (Not Supplied) - This unit requires a 13amp plug socket to run
- Daily Cube Output (KG) 73 KG / 24hr
- Ice Type Flaked
- Max Ambient Temperature 40°C
- Width (External) 535mm
- Height (External) 889mm
- Depth (External) 626mm
- Bin Capacity 25 KG
- Water Fill Type Autofill
- Built In Drain Pump No
